ProX XT-HEART984 Square Framed HEART Truss Package (7 Segments) F34

The exclusive ProX XT-HEART984 is one of the most unique trussing elements you will find.  Incorporate this into your truss designs and you will stand out from the competition.

ProX Truss has the most trusted staging support systems in the industry, and is built to the highest standards of safety and performance. It's a rugged yet lightweight trussing solution perfect for mobile DJs, bands, outdoor performances, nightclubs, live mobile productions, or permanent installations.

At the heart of the system is square truss that utilize a standard conical connector system, which easily mates with other brands of truss of the same size and connector style, and is available in a variety of lengths to suit your designs. It also works with different types of corners, base plates, connectors and accessories that add stability while expanding on limitless configurations.

• Tolerance Free Standard Conical connector
• Main tube wall thickness of .08in

XT-SQ SERIES DIMENSIONS:

• Height: 11.42in / 290mm
• Width: 11.42in / 290mm
• Weight: 21lb per 3.28 ft / 9,5kg per meter
• Main Tube: 2in / 50mm
• Wall Thickness:  .08in / 2mm
• Braces: .75in / 20mm

Actual Height:  Decorative Truss Segment
Actual Weight: 175 lbs.

Heart Dimensions: (Est.)  11ft (3.35m) Tall  and 12.33ft (3.75m) Wide
Outside: 290mm - 11 7/16"
Tubing: 2"
Bracing: 3/4"
Includes all connecting hardware

ProX Truss products utilize industry standard dimensions to be compatible to connect to/with many other manufacturers trussing.

Features

• 1 XT-CSQ656-4x90 Square Frame Circular Truss 4 Segments 6.56 FT 2m
• 1 XT-JB6W-2W Square Truss Junction Block 2 Way
• 2 XT-SQ492 4.92ft(1.50m) Square Truss Segment
• 1 XT-SQ164-2W90 Square Truss Corner 2 Way 90 Degree
• Manufactured in our Own Factory!
• Material: EN-AWT6 6082 Aluminum
• TUV Certified Aluminium Welding

TUV Is a 3rd Party Certification Body and a Nationally Recognized Testing Laboratory (NRTL).  TUV provides inspections, testing, certification & training, with the ultimate objectives of reliability, safety & high quality.

To Fit

Standard F34 Square Truss Configurations.
