The Obra Flood N180 is a low profile wash unit that can be used to distribute bright colors evenly across any stage. It's equipped with sixty 3W LEDs, it has nine different colors (red, dark red, fire red, green, aqua, lime, blue, indigo and amber) that can be used to create an assortment of various colors. It is designed to create a clean wash effect, smooth color mixing transitions and generate vibrant colors that can transform any venue.

Features

• Colors: The Obra Flood N180's Compact design allows for many Versatile uses.
• MOUNTING: The Obra Flood comes with a variety of vibrant Colors including Dark red, red, fire red, green, aqua, lime, blue, indigo, and amber.
• BARN DOORS: The included barn doors allow for a more controllable projection.

Specifications

Source

• LED Type: 60 Single Color LEDs
• LED Watts: 3 Watts Each

Optical System

• Lens Angle: 97
• Barndoors: Included
• Diffuser: Included

Effects

• Color Type: Dark Red, Red, Fire Red, Green, Aqua, Lime, Blue, Indigo, Amber
• Cri: 62 On All Colors On
• Cct: 10809K @ Full

Control and Programming

• Display: Digital
• Protocol: DMX 512
• Rdm: Yes
• DMX Channels: 4 Modes Of Operation

Movement

• Tilt: Manual

Thermal and Ratings

• Max Ambient Temp: 40C (104f)
• Max Surface Temp: 60C (140f)
• IP Rating: IP20

Electrical and Connections

• Power Connection: Panel Mount Power Con Type In/Out
• Signal Connectors: Panel Mounted 5-Pin Xlr Connectors In/Out
• Power Supply: Universal 100V-240V 50/60Hz

Rigging:

• Installation System: Accessory Clamp Fixture Track Mounts

Included Items:

• Power Cable

Dimensions:

• Fixture Size: 12.75" X 5.33" X 11.75"
• Fixture Weight: 14 Lb
• Packaged Size: 15" X 12.5" X 8"
• Packaged Weight: 15 Lb
