Overview
Extremely approachable EAWmosaic™ iOS app delivers system prediction, control and monitoring from any location in the venue.
Proven EAW acoustical design and DSP including Focusing™ and DynO™ provides a pristine impulse response at all output levels.
Integrated Dante™ networking (with loop-thru) on all models including Analog redundancy capability.
Specifications
Configuration
- Subsystem
- Transducer: LF – 1 x 8 in cone, 2 in voice coil; HF – 1 x 1 in exit, 1.4 in voice coil compression driver
- Loading: LF – Vented; HF – Horn-loaded
- Operating Mode
- Amplifier Channels: Bi-amp (LF/HF)
- Signal Processing: DSP w/EAW Focusing™and DynO™
Performance
- Operating Range: 48 Hz to 20 kHz
- Nominal Beamwidth
- Horizontal 90°
- Vertical 60°
- Calculated Axial Output Limit (whole space SPL)
- Average: 130 dB (LF/HF)
- Peak: 136 dB (LF/HF)
- Input
- Type: Electronically balanced
- Max Input Level: 21dBu
- Impedance: 20 kOhm (balanced)
- Input Wiring: XLRF, Pin 1 chassis, pin 2 +, pin 3 – separate loop-thru XLRM (for analog signal only)
- Input Selection: Analog, Dante
- Amplifiers & Processing (LF)
- Type: Modified Class D (LF/HF)
- Maximum Output: 500W (LF/HF)
- Driver Protection: Integral DSP limiting
- AC Mains (nominal)
- Connector: Neutrik PowerCon®
- Input: 100 V to 240 V
- Frequency: 50 Hz to 60 Hz
- PowerConsumption
- Idle – 50W
- Peak Draw – 500 W
- Controls/Communication
- Connections: 2x Neutrik® etherCON™, RJ-45
- Protocols: Ethernet/Dante
- Software: EAWmosaic™ (available on the App Store)
- Indicators: LCD Screen on amplifier panel for UI, Logo LED (User-definable behavior)
- User Controls: Push-button Rotary Encoder
