Overview:
ZERO-OHM System is a passive device that interconnects between any amplifier and multiple loudspeakers without the concerns of amplifier speaker loads, impedance and extremely long cable runs. This Patented Design eliminates the need for 70V-100V transformer products. Multiple loudspeakers can be wired in a parallel connection to impedances below one (1) Ohm.
Features:
Zero (0) Ohm functionality
No Transformers required
Multiple loudspeakers can be connected in parallel
Any Speaker impedance can be used: 2/4/8/16 Ohm
Uniform power distribution over long distance cable runs
Full range frequency response
Identical Output Phase relationship with all Power Amplifiers
Pushing boundaries, and bending rules.
What if you could drive your amp to the edge of zero ohms without shutting down? The Zero-Ohm Multispeaker Systeminterconnects between any amplier and multiple loudspeakers without worrying about amplier speaker loads, impedance and extremely long cable runs. The patented design eliminates the need for 70V and 100V transformers. This device allows you to connect 20,30,40 or more speakers in parallel to one amplier. Up until now, the ability to connect multiple speakers in parallel was confronted by the issue of operating the amplier at a safe nominal wattage. Although there are ampliers that operate at 4 ohms and 2 ohms safely, any eort to drive it below the rated resistance led to device failures. With this revolutionary invention, the rules have changed.
Specs:
Frequency Response 20Hz - 20kHz
Frequency Range 20Hz - 20kHz
Total Harmonic Distortion < 0.1% (20W RMS at Complex Load)
ORDER INFORMATION
4K-2 Two Channel Rackmount System P/N: 4K-2
COUNTRY OF ORIGIN Made in Canada
AUDIO
Input/Output Connector Neutrik NL4
Input Pin-Out Pin 2+ Pin 2-
Output Pin-Out Pin 1+ Pin 1-
Min. Output Impedance 0.1 Ohms
Max. Power Handling 4000W (Per channel)
PHYSICAL PROPERTIES
Height 65.1mm
Width 438.1 mm / 479.4mm with Rack Ears
Depth 149.2 mm
Weight 3.2 kg
Shipping Weight 4kg (Including Packaging)
