Overview
Lo-Z/Hi-Z switchable Class-D mixer amplifier (Lo-Z: 30W x2ch, Hi-Z: 60W x1ch) equipped with 3 types of selectable stereo inputs, 2 mic inputs and powerful DSP functions for high quality music playback and microphone use.
Features
- Easy setup, and a user-friendly interface for effortless operation
- Supporting Lo-Z (30W @3Ω/4Ω/8Ω) and Hi-Z (60W x1ch, 70V/100V) speaker systems
- Flexible 2 mic inputs and selectable 3 stereo inputs
- Advanced DSP functions for music playback and microphone use (Feedback Suppressor, Priority Ducker, Leveler)
- Bass and treble stereo source EQ with enhancer function
- Built-in speaker EQ optimum for Yamaha VXC/VXS series speaker
- Built-in HPF
- Service zone can be expanded by adding a PA2030a
- Remote volume control and microphone on/off switching via the optional DCP control panels (DCP1V4S, 1 DCP panel per unit)
- Intelligent protection function ensures safe, reliable operation
- Certified as Yamaha Eco Products
- Space-saving 1U rack size (*sufficient space must be provided above and below the unit for airflow and cooling.)
