| CONSTRUCTION & DIMENSIONS | - |
| CONDUCTOR PARAMETER | - |
| Number of Pairs | 2 |
| AWG Size | 18 |
| Conductor Stranding | 7x26 |
| Conductor Type | Tinned Copper |
| Nominal DCR | 10.5 Ohm/1000ft |
| INSULATION PARAMETER | - |
| Insulation Type | Polypropylene - PP |
| Insulation Thickness | 0.008 in |
| Insulation Color Code | 1. Black-Rd, Red, 2.Black-Wh, White |
| SHIELDING PARAMETER | - |
| Shield Type | Individually Shielded |
| Drain Wire Type | Tinned Copper |
| Drain Wire AWG | 24 AWG |
| ELECTRICAL CHARACTERISTICS | - |
| Nom. Cap. Between Conductors | 40 pF/ft |
| Nom. Cap. Conductor to Shield | 73 pF/ft |
| OVERALL CONSTRUCTION PARAMETERS | - |
| Total Number of Conductors | 4 |
| Jacket Type | PVC |
| Jacket Thickness | 0.017 in |
| Nominal Cable O.D. | 0.268 in |
| Plenum | No |
| NEC UL Rating | CM |
| RoHS Compliant | Yes |
| Pull Tension | 100 lbs |
| Bend Radius | 2.412 in |
| Cable Weight | 38 lbs |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | - |
| UL Flammability | UL1685 |
| Operating Range | -20 to 60 Deg C |
| UL Voltage Rating | 300 |
