| CONSTRUCTION & DIMENSIONS | - |
| CONDUCTOR PARAMETER | - |
| Number of Pairs | 2 |
| AWG Size | 22 |
| Conductor Stranding | 7x30 |
| Conductor Type | Tinned Copper |
| Nominal DCR | 17 Ohm/1000ft |
| INSULATION PARAMETER | - |
| Insulation Type | FEP |
| Insulation Thickness | 0.007 in |
| Insulation Color Code | 1.Black-Red,2.White-Green |
| SHIELDING PARAMETER | - |
| Shield Type | Individually Shielded |
| Drain Wire Type | Tinned Copper |
| Drain Wire AWG | 24 AWG |
| ELECTRICAL CHARACTERISTICS | - |
| Nominal Impedance | 55 Ohm |
| Nom. Cap. Between Conductors | 25 pF/ft |
| Nom. Cap. Conductor to Shield | 45 pF/ft |
| OVERALL CONSTRUCTION PARAMETERS | - |
| Total Number of Conductors | 4 |
| Jacket Type | Flexible Plenum |
| Jacket Thickness | 0.017 in |
| Nominal Cable O.D. | 0.14 in |
| Plenum | Yes |
| NEC UL Rating | CMP |
| RoHS Compliant | Yes |
| Pull Tension | 51 lbs |
| Bend Radius | 1.26 in |
| Cable Weight | 32 lbs |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | - |
| UL Flammability | NFPA 262 Plenum |
| Operating Range | -0 to 60 Deg C |
| UL Voltage Rating | 300 |
