Overview
The U-13R is an AUX module to be used in conjunction with the 900 series or AX-1000 amplifier. It has an input that can control muting operations of a signal output.
Specifications
| Power Source | 24 V DC |
|---|---|
| Current Consumption | Under 11 mA |
| Input Sensitivity (Rated Output 100 mV ) | 100 - 3,600 mV (adjustable) |
| Low Cut Filter (100 Hz ) | -5 to -15 dB |
| High Cut Filter (10 kHz ) | -7 to -13 dB |
| Noise Output (20 Hz - 20 kHz BPF) | Under 10 μV |
| Distortion | Under 0.05 % |
| Frequency Response | 20 Hz - 20 kHz |
| Signal Muting Level | Over 50 dB |
| Input Connector | RCA pin jacks |
| Output Connector | 6P card edge-connector |
| Dimensions | 35 (W) × 78 (H) × 88 (D) mm |
| Weight | 50 g |
