Overview

The Shure Microflex Ecosystem 712P AV Conferencing Bundle includes MXA710-2FT Linear Array Microphones, an P300-IMX, and a MXN5W-C + Tile Bridge.

The MXA710 Linear Array Microphone represents the next evolution in Shure array microphone technology, designed for high-quality audio capture in premium AV conferencing environments. The sleek, linear form factor of the MXA710 allows for placement virtually anywhere in a meeting space, including on a wall, around a display, ceiling, or into a conference room table. Available in two lengths and three colors, the MXA710 includes proprietary Shure IntelliMix® DSP and Autofocus™ technology that provides all the processing needed for echo and noise-free conference audio.

The Microflex™ MXN5W-C Networked Ceiling Loudspeaker provides high-quality speech reproduction for AV conferencing applications. Gone is the need for a separate amplifier or an outboard DSP, the PoE-powered MXN5 is the ideal loudspeaker solution when used as part of a Shure networked conferencing audio system. Combined with Microflex Advance Array Microphones and IntelliMix® DSP, the full Shure networked systems ecosystem delivers premium audio performance with unmatched ease of deployment, with the added confidence of Shure Audio Encryption and Dante Domain Manager compatibility.

Specifications

710

• Adjustable Lobe Width
  • Narrow: 30 degrees
  • Medium: 40 degrees
  • Wide: 70 degrees
• Connector Type: RJ45
• Power Requirements: Power over Ethernet (PoE), Class 0
• Power Consumption: 10W maximum
• Weight: 2 lbs (0.91 kg)
• Product Dimensions (HxWxL): 0.87x2.36x25.04" (22.09x60x636mm)
• Control Software: Shure Designer
• Plenum Rating: UL2043 (Suitable for Air Handling Spaces)
• Dust Protection: IEC 60529 IP5X Dust Protected
• Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
• Storage Temperature Range: −29°C (-20°F) to 74°C (165°F)
• Audio Frequency Response: 100 Hz to 20 kHz
• AES67 or Dante Digital Output
  • Channel Count: 6 total channels (4 independent transmit channels, 1 Automix output, 1 AEC reference in channel)
• Sampling Rate: 48 kHz
• Bit Depth: 24
• Sensitivity (at 1 kHz): -7.4 dBFS/Pa
• Maximum SPL (Relative to 0 dBFS overload): 101.4 dB SPL
• Signal-To-Noise Ratio (Ref. 94 dB SPL at 1 kHz): 71.2 dB A-weighted
• Latency (Does not include Dante latency)
  • Direct Outputs: 8.7 ms
  • Automix output (Includes IntelliMix processing): 19.3 ms
• Self Noise: 22.9 dB SPL-A
• Dynamic Range: 78.5 dB
• Built-in Digital Signal Processing: Automatic mixing, Acoustic Echo Cancellation (AEC), Noise Reduction, Automatic Gain Control, Compressor, Delay, Equalizer (4-band Parametric), Mute, Gain (140 dB range)
• Acoustic Echo Cancellation Tail Length: Up to 250 ms
• Networking Cable Requirements: Cat 5e or higher (shielded cable recommended)

MXN5W-C + Tile Bridge

• Connector Type: RJ45
• Power Requirements: Power over Ethernet (PoE Class 0) or PoE Plus (Class 4)
• Weight: 6.5 lbs (2.95 kg)
• Product Dimensions (HxWxD): 12x12x4" (304.8x304.8x101.6mm)
• Control Software: Shure Designer
• Plenum Rating: UL 2043 (Suitable for Air Handling Spaces)
• Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
• Storage Temperature Range: −29°C (20°F) to 74°C (165°F)
• Frequency Response (-3 dB): 120 Hz to 20 kHz
• Digital Signal Processing: Delay, Limiter, Signal Generator, Equalizer (4-band Parametric)
• Latency: 1.5 ms (Not including Dante latency)
• POWER CONSUMPTION
  • Power over Ethernet (PoE): 12W maximum (11W typical)
  • PoE Plus: 24W maximum (23W typical)
• MAXIMUM OUTPUT LEVEL COVERAGE ANGLE
  • Power over Ethernet (PoE) @ 1 meter: 92 dB SPL -6 dB at 2 kHz 180 degrees
  • PoE Plus @ 1 meter: 98 dB SPL -6 dB at 10 kHz 107 degrees

P300

• General
  • Input: (2) 3-pin block connector (Active Balanced)
  • Output: (2) 3-pin block connector (Impedance Balanced)
  • Mobile: (1) TRRS 3.5 mm (1/8″)
• USB Connections ((1) USB 2.0, Type B): Single port carries 2 input and 2 output channels (Summed mono)
• Network Connections (Dante Digital Audio); ((1) RJ45): 10 Dante Inputs, 8 Dante Outputs
• Polarity: Non-inverting, any input to any output
• Power Requirements: 802.3 at Type 2 (PoE Plus), Class 4
• Power Consumption: 17.5W, maximum
• Weight: 1710 g (3.8 lbs)
• Dimensions (HxWxD): 4x21x22.6cm (1.6x8.3x8.9”)
• Control Software: Shure Designer
• Operating Temperature Range: −6.7°C (20°F) to 50°C (122°F)
• Storage Temperature Range: −29°C (­20°F) to 74°C (165°F)
• Thermal Power Dissipation
  • Maximum 17.5 W (60 BTU/hr)
  • typical 14.6 W ( 50 BTU/hr)
• Audio
  • Frequency Response (+1, ­1.5 dB): 20 to 20,000 Hz
  • Dante Digital Audio
    • Sampling Rate: 48 kHz
    • Bit Depth: 24
  • USB Audio
    • Sampling Rate: 48 kHz
    • Bit Depth: 16, 24
  • Latency (Does not include Dante latency)
    • Firmware 4.1 and newer
      • Dante 1-8 in to Dante out (AEC enabled) 15.4 ms
      • Dante 1-8 in to Dante out (AEC disabled) 8.7 ms
      • Dante 9-10 in to Dante out 3.4 ms
      • Analog in to Analog out 3.8 ms
    • Firmware 3.1 and older
      • Dante 1-8 in to Dante out (AEC enabled) 12.5 ms
      • Dante 1-8 in to Dante out (AEC disabled) 5.8 ms
      • Dante 9-10 in to Dante out 1.8 ms
      • Analog in to Analog out 2.2 ms
  • Acoustic Echo Cancellation Tail Length: Up to 300 ms
• Analog Connections (Block Connectors)
  • Dynamic Range (20 Hz to 20 kHz, A-weighted, typical)
    • Analog-to-Dante: 113 dB
    • Dante-to-Analog: 117 dB
  • Equivalent Input Noise (20 Hz to 20 kHz, A­weighted, input terminated with 150Ω)
    • Line ­86 dBV
    • Aux ­98 dBV
  • Total Harmonic Distortion (@ 1 kHz, 0 dBV Input, 0 dB analog gain): <0.05%
  • Common Mode Rejection Ratio (150Ω balanced source @ 1 kHz): >50 dB
  • Input Impedance: 9.6 kΩ
  • Input Clipping Level
    • Line: +27 dBV
    • Aux: +15 dBV
  • Output Impedance: 80 Ω
  • Output Clipping Level
    • Line: +20 dBV
    • Aux: +0 dBV
    • Mic: ­26 dBV
• Mobile Connection (3.5 mm Connector)
  • Pin Assignments
    • Tip: Audio Input (Left)
    • Ring 1: Audio Input (Right)
    • Ring 2: Ground
    • Sleeve: Audio Output (To Phone)
  • Dynamic Range (20 Hz to 20 kHz, A-weighted, typical)
    • Analog-to-Dante: 99 dB
    • Dante-to-Analog: 90 dB
  • Equivalent Input Noise (20 Hz to 20 kHz, A­weighted, input terminated with 20Ω): ­95 dBV
  • Total Harmonic Distortion (@ 1 kHz, 0 dBV Input, 0 dB analog gain): <0.05%
  • Input Impedance: 3.7 kΩ
  • Input Clipping Level: +4 dBV
  • Output Impedance: 1.4 kΩ
  • Output Clipping Level (Output terminated with 2.2 kΩ): ­20 dBV
• Networking
  • Cable Requirements: Cat 5e or higher (shielded cable recommended)
• Mobile Pin Assignments (TRRS)
  • Tip: Audio Input (Left)
  • Ring 1: Audio Input (Right )
  • Ring 2: Ground
  • Sleeve: Audio Output (To Phone)
  • Note: The audio input (tip and ring 1) are summed to a mono signal in the P300, to send the signal to any destination on a single channel.
