Overview

The Shure Microflex Ecosystem 712M AV Conferencing Bundle includes two MXA710-2FT Linear Array Microphones, an IMX-RM8-SUB5 subwoofer, and two MXN5W-C + Tile Bridges.

The MXA710 Linear Array Microphone represents the next evolution in Shure array microphone technology, designed for high-quality audio capture in premium AV conferencing environments. The sleek, linear form factor of the MXA710 allows for placement virtually anywhere in a meeting space, including on a wall, around a display, ceiling, or into a conference room table. Available in two lengths and three colors, the MXA710 includes proprietary Shure IntelliMix® DSP and Autofocus™ technology that provides all the processing needed for echo and noise-free conference audio.

The Microflex™ MXN5W-C Networked Ceiling Loudspeaker provides high-quality speech reproduction for AV conferencing applications. Gone is the need for a separate amplifier or an outboard DSP, the PoE-powered MXN5 is the ideal loudspeaker solution when used as part of a Shure networked conferencing audio system. Combined with Microflex Advance Array Microphones and IntelliMix® DSP, the full Shure networked systems ecosystem delivers premium audio performance with unmatched ease of deployment, with the added confidence of Shure Audio Encryption and Dante Domain Manager compatibility.

Specifications

710

• Adjustable Lobe Width
  • Narrow: 30 degrees
  • Medium: 40 degrees
  • Wide: 70 degrees
• Connector Type: RJ45
• Power Requirements: Power over Ethernet (PoE), Class 0
• Power Consumption: 10W maximum
• Weight: 2 lbs (0.91 kg)
• Product Dimensions (HxWxL): 0.87x2.36x25.04" (22.09x60x636mm)
• Control Software: Shure Designer
• Plenum Rating: UL2043 (Suitable for Air Handling Spaces)
• Dust Protection: IEC 60529 IP5X Dust Protected
• Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
• Storage Temperature Range: −29°C (-20°F) to 74°C (165°F)
• Audio Frequency Response: 100 Hz to 20 kHz
• AES67 or Dante Digital Output
  • Channel Count: 6 total channels (4 independent transmit channels, 1 Automix output, 1 AEC reference in channel)
• Sampling Rate: 48 kHz
• Bit Depth: 24
• Sensitivity (at 1 kHz): -7.4 dBFS/Pa
• Maximum SPL (Relative to 0 dBFS overload): 101.4 dB SPL
• Signal-To-Noise Ratio (Ref. 94 dB SPL at 1 kHz): 71.2 dB A-weighted
• Latency (Does not include Dante latency)
  • Direct Outputs: 8.7 ms
  • Automix output (Includes IntelliMix processing): 19.3 ms
• Self Noise: 22.9 dB SPL-A
• Dynamic Range: 78.5 dB
• Built-in Digital Signal Processing: Automatic mixing, Acoustic Echo Cancellation (AEC), Noise Reduction, Automatic Gain Control, Compressor, Delay, Equalizer (4-band Parametric), Mute, Gain (140 dB range)
• Acoustic Echo Cancellation Tail Length: Up to 250 ms
• Networking Cable Requirements: Cat 5e or higher (shielded cable recommended)

MXN5W-C + Tile Bridge

• Connector Type: RJ45
• Power Requirements: Power over Ethernet (PoE Class 0) or PoE Plus (Class 4)
• Weight: 6.5 lbs (2.95 kg)
• Product Dimensions (HxWxD): 12x12x4" (304.8x304.8x101.6mm)
• Control Software: Shure Designer
• Plenum Rating: UL 2043 (Suitable for Air Handling Spaces)
• Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
• Storage Temperature Range: −29°C (20°F) to 74°C (165°F)
• Frequency Response (-3 dB): 120 Hz to 20 kHz
• Digital Signal Processing: Delay, Limiter, Signal Generator, Equalizer (4-band Parametric)
• Latency: 1.5 ms (Not including Dante latency)
• POWER CONSUMPTION
  • Power over Ethernet (PoE): 12W maximum (11W typical)
  • PoE Plus: 24W maximum (23W typical)
• MAXIMUM OUTPUT LEVEL COVERAGE ANGLE
  • Power over Ethernet (PoE) @ 1 meter: 92 dB SPL -6 dB at 2 kHz 180 degrees
  • PoE Plus @ 1 meter: 98 dB SPL -6 dB at 10 kHz 107 degrees
