Overview

MMR 30T is a full-range wall-mount monitor speaker designed to meet a wide variety of needs in both indoor and outdoor applications. Thanks to its refined finishes and discreet design, it blends seamlessly into any architectural context. Featuring a 3” woofer and 10 W RMS power, this compact speaker also comes with an integrated transformer for connection to 100 V constant voltage lines. Its highquality transducer guarantees faithful musical reproduction across the entire audio spectrum, reaching remarkable sound pressure levels for such a small device. The connection is simple and secure through removable two-pole screw terminals.

MULTIPURPOSE SOUND

With a frequency response from 200 Hz to 20 kHz and a maximum SPL of 101 dB, MMR 30T ensures clear audio for both background music and speech applications. MMR 30T seamlessly integrates with DMA series amplifiers, providing broad compatibility with the entire Business Music line for an expanded range of possible configurations.

FEATURES

• 10W RMS power handling
• 101 dB max SPL
• 200 - 20000 Hz frequency range
• 130° constant directivity conical coverage angle
• 3" full range transducer
• ABS body and aluminum grille
• Wall mount bracket included
• IP 55 protection grade
• 2 pole EUROBLOCK connector

Specifications

Acoustical

• Frequency Response (-10dB): 200 Hz - 20000 Hz
• Max SPL @ 1m: 101 dB
• Coverage angle: 130°
• System Sensitivity: 84 dB

Power section

• Amplification: Full Range
• Nominal Impedance: 16 ohm
• Power Handling: 10 W RMS
• Peak Power Handling: 40 W PEAK
• Recommended Amplifiers: DMA 504, DMA 162, DMA 82, DMA 162P

Transducers

• Woofer: 1 x 3.0”

Input/Output section

• Input connectors: Euroblock
• Output connectors: Euroblock
• Constant Voltage Transformer: 100 V
• Power selection 1: 10 W - 1000 ohm
• Power selection 2: 5 W - 2000 ohm
• Power selection 3: 2.5 W - 4000 ohm
• Power selection 4: 1.25 W - 8000 ohm

Standard compliance

• Safety agency: CE compliant

Physical

• Cabinet/Case Material: ABS
• Grille: Aluminum
• Color: Black - White

Size Height

• Depth: 96.3 mm / 3.79 inches
• Recessed Depth: 100.3 mm / 3.95 inches
• Diameter: 148.8 mm / 5.86 inches
• Weight: 0.66 kg / 1.46 lbs
