Overview

1-inch/1.4 inch Throat Adaptor.60° x 40° Constant Directivity Coverage. Thick Aluminum Body for best heat dissipation in conjuntion to Neodimium Compression Drivers.

Features

• 1-inch/1.4 inch Throat Adaptor
• 60° x 40° Constant Directivity Coverage
• Loading down to 500 Hz
• Thick Aluminum Body for best heat dissipation in conjuntion to Neodimium Compression Drivers
• Perfectly Controlled Dispertion

Specifications

General

• Throat Diameter: 25-36 mm / 1.0 inch
• Horizontal coverage angle: 60°
• Vertical coverage angle: 40°
• Cut-off Frequency: 500 Hz
• Material: Aluminum

Mounting

• Overall height: 250 mm / 9.84 inches
• Overall width: 25 mm / 0.98 inches
• Overall depth: 179 mm / 7.05 inches
• Baffle Cut-out height: 205 mm / 8.07 inches
• Baffle Cut-out width: 205 mm / 8.07 inches
• Mounting: 4 x 7 mm holes, interaxes 101 mm/76 mm

Standard compliance

• Safety agency: CE compliant

Physical

• Cabinet/Case Material: Metal
• Color: Black - RAL 9005, White - RAL 9003

Size / Weight

• Height: 186 mm / 7.32 inches
• Diameter: 250 mm / 9.84 inches
• Weight: 1.48 kg / 3.26 lbs
