Features
- Consistent Levels from Variable Sources
- Split-Band AGC for Audio Transparency
- Self-Adjusting Attack and Release Times
- AGC with Simple Single-Control Setup
- Level Control Range > 20 dB
- Gated Control to Avoid Level Seeking
- Convenience of RDL FLAT-PAKs
Specifications
| Inputs (2) | 10 k? unbalanced phono jack |
| Input Level | -10 dBV (nominal) |
| Outputs (2) | 200 ? unbalanced phono jack |
| Output Level | -10 dBV |
| Automatic Level Range | -30 to 0 dBV |
| Gate Threshold | -40 dBV (20 Hz to 3 kHz) |
| Frequency Response (excluding AGC) | 20 Hz to 20 kHz (± 0.5 dB) |
| THD+N
< 0.15% (20 Hz to kHz)
|
|
| Noise | < -90 dB (below ?10 dBV) |
| Headroom | > 18 dB |
| Indicator (1) | INPUT OVERLOAD |
| Ambient Operating Environment | 0° C to 55° C |
| Power Requirement | GROUND-REFERENCED, 24 Vdc @ 80 mA |
| Overall Dimensions | Height: 1.20 in. 3.05 cm; Width: 3.25 in. 8.26 cm; Length: 5.75 in. 14.61 cm |
| Package Type | Cardboard Box |
| Package Dimensions | 4.375 x 7 x 2.25 in. |
| Shipping Weight | 0.88 lbs. |
| WEEE weight | 0.63 lbs. |
| Tariff code | 8518.40.2000 |
