RDL DS-J3C

Mic/Line Input Assembly-XLR, RCA, Terminal block-Stainless (Custom Labeled) (See Part#ZCST-LBL for setup charge)

SKU: RDL-DS-J3C
MSRP: $111.44
MAP: $83.58

(Custom Labeled)

Overview

The D SERIES-J3 is a complete audio input panel assembly. The front panel features a female XLR jack and two phono jacks. The XLR is connected directly to the rear-panel barrier block. The phono jacks are intended for mono or stereo consumer level sources. LEFT and RIGHT are combined and balanced through audio transformers configured to reject induced hum. The line-level output is provided on the rear-panel terminal block for connection to 10 k? or higher input impedance line level module or equipment inputs. The back of the D SERIES-J3 is finished with a metal enclosure clearly labeled for easy installation.

The D SERIES-J3 fits directly into back boxes, available from RDL to fit cabinets or US or international walls (RDL WB-1U). They may be mounted directly into cabinets or most standard US single gang electrical boxes.

Features

  • Wall Mounted Audio Inputs
  • XLR Microphone Input with Gold Contacts
  • Gold Plated Phono Jack Line Inputs
  • Hum Cancellation on Unbalanced Line Inputs
  • Transformer Isolation for Unbalanced Line Inputs
  • Balanced Mono Output for Unbalanced Mono or Stereo Line Inputs

Specifications

Input ConnectorsXLR female with gold contacts (1); Phono jacks with gold contacts (2)
Output ConnectorTerminal block
Output Connections (5)Line: +, -, SHIELD; Mic: SHIELD (XLR pin 1), + (XLR pin 2), - (XLR pin 3)
Frequency Response (line in)30 Hz to 20 kHz (±1 dB)
Power RequirementPassive
DimensionsHeight: 4.13 in. 10.49 cm; Width: 1.7 in. 4.32 cm; Depth: 2.15 in. 5.47 cm
Mounting Box Req.Width: 1.80 in. 4.57 cm; Depth: 1.75 in. 4.45 cm
Package TypeCardboard Box
Package Dimensions3.625 x 4.625 x 2.125 in.
Shipping Weight0.515 lbs.
WEEE weight0.36 lbs.
Tariff code8536.69.4030
