Overview
The QSC AcousticCoverage™ AC-C6T is a ceiling-mounted 6” two-way loudspeaker with 70/100V transformer, suitable for a wide variety of voice paging and background music sound reinforcement applications.
AcousticCoverage™ is designed to offer integrators a cost-effective solution for applications where voice reinforced coverage is of primary concern, while providing improved musicality often not seen in typical BGM class products.
The high quality 6" polypropylene cone transducer with butyl rubber surround and the sensitivity matched coaxially mounted 0.86" silk dome tweeter offers pristine clarity through the critical vocal range for increased speech intelligibilty. With 110 degrees of conical coverage, the AC-C6T reduces the number of loudspeakers required for even coverage in low ceiling applications.
The easy-to-install blind mount assembly features a ported baffle which optimally tunes the galvanized steel backcan for added musicality, creating low frequency extension down to 65 Hz. To maintain this frequency response, the AC-C6T utilizes a 30W low-saturation and low-loss 70/100V transformer with varying selectable taps, including an 8Ω bypass. The rotary tap selector switch is accessible under the painted steel grille.
To further enhance performance and speed of install with optimum result, advanced voicing via QSC Intrinsic Correction™ techniques are obtainable using Q-Sys™ networked audio processing platforms, including CXD amplifiers for a complete QSC systems solution. Installers will appreciate the 4-pole Euroblock connector for loop-thru wiring, located under a quick access swivel plate. Eliminating the termination hassles of star topology wiring designs, the generous Euroblock of the AC-C6T can accept four 18AWG pairs.
A safety tether tab is affixed to the adjustable conduit clasp plate for seismicsensitive installations. C-ring and tile rails are included with each pair packed assembly, complete with joining screws and cut-out template. The AC-C6T baffle and grille are QSC standard white (RAL 9010) to match complimenting QSC product families and includes UV inhibitors to prevent discoloration over time. The AC-C6T may also be painted to match any décor.
Priced inidvidually but sold in pairs.
Features
- High quality transducers provide clarity through the critical voice range
- Ported baffle for increased low frequency extension down to 70 Hz
- Low saturation 70/100V transformers with 8 ohm bypass
- 4-pole Euroblock connector eases system wiring
- Advanced voicing via QSC Intrinsic Correction, applied using Q-Sys processing or CXD amplifier platforms
- Complete EASE, CAD & BIM information available online
Specs
| Frequency Range | 60 Hz to 20 kHz |
| Noise Power | 30 W/15.5 V rms |
| Broadband Noise | 86 dB SPL |
| Coverage Angle | 130° conical, 500 Hz to 5 kHz @ -6 dB |
| Directivity Factor | 6 |
| Directivity Index | 8 dB |
| Maximum SPL | Continuous: 101 dB Peak: 107 dB |
| Rated Impedance | 8 ohms |
| Recommended Amplifier Power | 60 W into 8 ohms |
| Transformer Taps | 70 V: 30, 15, 7.5, 3.7, 1.9 W 100 V: 30, 15, 7.5, 3.8 W 8 ohm bypass |
| Low Frequency Transducer | 6.5" (165 mm) Polypropylene woofer with 1" (25 mm) voice coil |
| High Frequency Transducer | 1" (25 mm) Aluminum dome tweeter with 1" (25 mm) voice coil |
| Input Connection Type | Euroblock connector with parallel output |
| Enclosure Material | UV treated, high impact ABS polymer |
| Grille Material | Powder-coated steel |
| Yoke Material | Powder-coated steel with brass inserts |
| Enclosure Characteristics | Ingress Protection: IP-44 Operating environment: Designed for indoor use Operating Temperature: -4 to 122°F (-20 to 50°C) |
| Dimensions | 11.9 x 8.5 x 7.8" (303 x 215 x 197 mm) |
| Weight | 8.3 lb (3.8 kg) |
