Overview
The AC-C6T Acoustic Ceiling Mount Loudspeaker from QSC is a 6" ceiling-mounted two-way loudspeaker with 70/100V line transformer, suitable for a wide variety of voice paging and background music sound reinforcement applications. The loudspeaker features a 6" polypropylene cone transducer with a butyl rubber surround and a coaxially mounted.86" silk dome tweeter. It features 110° of conical coverage. The blind mount assembly features a ported baffle which tunes the galvanized steel backcan for added musicality, creating a low frequency extension down to 65 Hz. To maintain this frequency response, the AC-C6T utilizes a 30W low-saturation and low-loss 70/100V transformer with varying selectable taps, including an 8-ohm bypass.
The rotary tap selector switch is accessible under the painted steel grille. The AC-C6t features a 4-pole Euroblock connector for loop-thru wiring, located under a quick access swivel plate which can accept four 18AWG pairs. A safety tether tab is affixed to the adjustable conduit clasp plate for seismic sensitive installations. C-ring and tile rails are included with each pair packed assembly, complete with joining screws and cut-out template.The AC-C6T baffle and grille are QSC standard white (RAL 9010) to match complementing QSC product families and includes UV inhibitors to prevent discoloration over time. The AC-C6T may also be painted to match any décor.
Features
- High quality 6” 2-way system provides exceptional clarity through the critical voice range.
- Low-saturation 70V/100V transformers with 8-ohm bypass.
- 4-pole Euroblock connector for easy system wiring.
- Advanced voicing filter sets using QSC Intrinsic Correction™ are available through either Q-SYS processing or CXD amplifier platforms.
- White (RAL 9010) with UV inhibitors to match complementing QSC product families.
- Complete EASE, CAD, and BIM information available online.
Specs
| Effective frequency range | 65 Hz to 20 kHz |
| Rated noise power / voltage | 30 watts / 15.5 volts (rms) |
| Broad-band sensitivity | 89 dB SPL |
| Coverage angle (-6 dB) | 110° (500 Hz to 5 kHz) |
| Maximum continuous SPL | 104 dB |
| Maximum peak SPL | 110 dB |
| Rated impedance | 8 ohms |
| Transformer taps: | |
| 70 V: | 30, 15, 7.5, 3.7, 1.9 watts and 8-ohm bypass |
| 100V: | 30, 15, 7.5, 3.8, watts and 8-ohm bypass |
| HF Transducer | .86" silk dome tweeter, coaxially mounted |
| LF Transducer | 6" Polypropylene cone with butyl rubber surround |
| Input connector type | Euroblock connector with parallel output terminals |
| Baffle material | Painted ABS polymer |
| Grille material | Powder coated steel |
| Back can material | Galvanized steel |
| Testing | Listed UL1480, UL2043 safe for use in air handling space |
| Net weight | 7.6 lb / 3.5 kg |
| Product dimensions | 10.24" × 8.4” (260 × 213 mm) |
| Cut-out Dimensions | 9" (229 mm) |
| Ceiling Capture Thickness | 0.25" to 1.5" (6.35 to 38.1mm) |
| Shipping weight | 21 lb / 9.5 kg pair packed |
| Shipping dimensions | 24.5" × 12.5" × 12.8" (622 × 318 × 324 mm) |
| Included accessories | Rails and C-ring for ceiling tile installation |
All specifications are subject to change without notice.
