Overview:

The CM-S56T 6" 2-way surface-mount speaker delivers signature Pioneer audio quality to your installation with aesthetics to match. Featuring clear sound with uniform coverage, the CM-C56T's unique shape ensures an aesthetic fit whether the surface is flat or curved. Plus, with an IP54 ingress rating, the CM-S56T is resistant to water and dust so it can be used for certain outdoor applications.

A newly developed 1-inch soft-dome tweeter produces clear, defined highs that complement the ample bass response delivered by the Vortex Bass Accelerator Port. The bass-reflex port has been constructed with ribs to ensure that air flows without distortion, to maximize low frequencies, and eliminate any unwanted vibrations. With a dispersion angle of 110 x 110, you'll deploy fewer boxes to achieve the desired coverage.

The flexibility of operating at 8 ohms or on 70/100V lines makes the CM-S56T a great choice for new or existing installations. The included U-bracket makes surface mounting and adjustments quick and painless. The directivity can always be changed and then secured with an Allen wrench or screwdriver. There's also a pair of 60mm M6 mounting holes on the rear of the speaker for alternative deployment.

Pioneer CM-S56T Applications:

• Retail spaces
• Office buildings
• Schools
• Bars and restaurants

Pioneer CM-S56T Includes:

• 1 x U-bracket

Pioneer CM-S56T Features:

• 2-way ported bass reflex design
• 1-inch soft dome tweeter for defined high frequencies
• Flexible 8 ohm impedance or 70/100V operation
• Mounting U-bracket included
• IP54 ingress rating for dust and water resistance

Pioneer CM-S56T Specifications:

• Loudspeaker Type: Two-way passive, reflex-loaded
• Rigging and Hardware: 1 × U-bracket, 2 × M6 threaded mounting points on rear
• Grille: Punched Aluminum
• Enclosure: PP
• Frequency response (- 10 dB, Typical): 80 Hz - 20 kHz
• Sensitivity (1W/1m): 88 dB
• Nominal Impedance: 8 Ω
• Power Handling (RMS/Program): 60 W / 120 W, * IEC60268-5
• Transformer taps
• 70 V: 70 V: 60 W / 30 W / 15 W / 7.5 W
• 100 V: 100 V: 60 W / 30 W / 15 W
• Dispersion: 110 °H × 110 °V
• Maximum SPL: 113 dB (peak), * Calculated from the power handling and sensitivity
• Driver Configuration
• LF: 6" (114 mm) cone
• HF: 1" (25 mm) silk dome tweeter
• Connectors: Euroblock (4 pin) × 1 (input: +/-, loop-thru: +/-)
• Dimensions ( W x H x D): 214.1 x 332.3 x 183.5 mm, (8.43" x 13.08" x 7.22")
• Weight / piece: 5.1 kg / 11.2 lbs.
• Environmental: IP54
• Color: CM-S56T-K: Black , CM-S56T-W: White
• Packaging Type: 2 Pieces per package
