The SX218 delivers very high output levels and superb transient performance with minimal distortion.
Please note this product has been updated since January 2019 from an earlier iteration.
Features
- Dual-driver, direct radiating subwoofer
- 2 x 18” (460mm)/4” (100mm) voice coil, long excursion, ferrite magnet, waterproof cone
- Very high output capability
- Tour-grade plywood enclosure with flying inserts
Applications
- Touring sound reinforcement for small and medium-size venues
- Fixed installations in concert halls, theatres, ballrooms and HoW
- Sports stadium, arena installations & corporate AV events
- Outdoor restaurant, bar and hotel entertainment areas
- Concourses and Theme Parks
Specifications
| TYPE | Dual-driver, direct radiating subwoofer |
| FREQUENCY RESPONSE (1) | 35Hz – 150Hz ±3dB, -10dB @ 30Hz |
| DRIVER | 2 x 18” (460mm)/4” (100mm) voice coil, long excursion, ferrite magnet, waterproof cone |
| RATED POWER (2) | 2000W AES, 8000W peak |
| SENSITIVITY (10) | 105dB |
| MAXIMUM SPL (9) | 144dB |
| NOMINAL IMPEDANCE | 2 x 8Ω |
| DISPERSION (-6dB) | Omnidirectional/or Cardioid (paired) |
| ENCLOSURE | Multi-laminate birch/poplar ply |
| FINISH | Durable Polyurea Coating |
| PROTECTIVE GRILLE | Black perforated Zintec |
| CONNECTORS | 2 x NL4 type |
| PIN CONNECTIONS (INPUT) | LF1: 1+, 1- LF2: 2+, 2- |
| PINS CONNECTIONS (LINK) | LF1: 1+, 1- LF2: 2+, 2- |
| FITTINGS |
|
| DIMENSIONS (INCL SKIDS) |
|
| WEIGHT |
|
