The LE100 is an extremely compact, two-way passive monitor. It features a 12” (300mm) LF /1” (25mm) exit HF Coaxial Differential Dispersion driver to distribute sound evenly over the listening plane. The LF driver section has a 2.5” (65mm) voice coil and an efficient motor system with an aluminium demodulating ring to minimise distortion. The coaxial HF driver utilises a 1.75” (44mm) polyimide dome and features a low-compression phase-plug to reduce non-linearity associated with overly-high compression ratios.
Features
- Compact, two-way stage monitor
- Coaxial ‘point-source’ performance
- Differential Dispersion™ technology for consistent coverage
- Defined, near-rectangular coverage plane at head-height
- Low-profile plywood enclosure
- Integral pole-mount with removable bung
- M8 rigging inserts
- Multiple connectors for flexible deployment
Applications
- Stage monitor
- Pole-mounted fill/PA system
Specifications
| TYPE | Two-way passive, Coaxial Differential Dispersion stage monitor |
| FREQUENCY RESPONSE (5) | 78Hz-20kHz ± 3dB, -10dB @ 58Hz |
| DRIVERS |
|
| RATED POWER (2) | 300W AES, 1200W peak |
| SENSITIVITY (8) | 97dB |
| MAXIMUM SPL (9) | 129dB peak |
| NOMINAL IMPEDANCE | 8Ω |
| DISPERSION (-6dB) | 110°-60° horizontal, 60° vertical |
| CROSSOVER | 1.6kHz passive |
| ENCLOSURE | Birch/poplar ply |
| FINISH | Black textured paint |
| PROTECTIVE GRILLE | Black perforated steel with scrim cloth backing |
| BAFFLE ANGLE | 27˚ |
| CONNECTORS | 5 x NL4 type |
| PIN CONNECTIONS | 1+/1- |
| FITTINGS |
|
| DIMENSIONS | (W) 490mm x (H) 302mm x (D) 472mm (W) 19.3ins x (H) 11.9ins x (D) 18.6ins |
| DIMENSIONS INCL FEET | (W) 496mm x (H) 305mm x (D) 472mm (W) 19.5ins x (H) 12.0ins x (D) 18.6ins |
| WEIGHT | 18kg (39.7lbs) |
