Overview

The Tornado-KT2 has a proprietary 2” high-efficiency drive unit with a neodymium magnet structure and a suspension engineered for maximum linear excursion and minimum residual transducer interference. The cone transducer delivers an impressive maximum peak SPL of 107 dB, and has a wide operating frequency range from 150 Hz to 18 kHz with very low distortion.

The Tornado-KT2 comes with wall brackets for fixed installations on surfaces.

Features

Color Customizable
We have the ability to customize your project by color matching your system to any RAL code to help you to better integrate the speakers into a wide variety of venues.

Lightweight
We created a portfolio complete with lightweight products that are easy to transportation and quick to setup optimizing logistics, space, labor costs and time.

Visually Discreet
For architectural reasons, a visually discreet audio system may be required to integrate seamlessly with the layout without compromising sound quality.

Weather Resistant
We utilize the most durable and resistant materials when developing our products to protect and conserve the system regardless of the elements, rendering a K-array installation reliable and long-lasting.

Specifications

Acoustics

• Power Handling: 18 W (AES)
• Impedance: 8Ω - 32Ω (settable)70V version available upon request (KT2-HV)
• Frequency range: (-10 dB) 150 – 18 kHz (1)
• Maximum SPL: 101 dB (cont.) – 107 dB (peak) (2)

Coverage

• Horizontal: 90°
• Vertical: 90°

Crossover

• Type: External Crossover required
• Frequency: 150Hz 24dB/Oct minimum required

Transducers

• Full range: 2” neodymiun magnet woofer with 2 voice coils of 0.8”
• Impedance: 2 x 16 Ω

Power audio input

• Connectors: 4-pin Phoenix connector
• Connector: VoiceCoil A=1+ 1- VoiceCoil B=2+ 2-

Certifications

• IP: 54
• EVAC: EN54-24

Physical Overview

• Dimensions: 7.4 x 12.1 x 11.7 cm (2.93”x 4.76”x 4.62”)(3) KT2 12,5 x 12,5 x 11,9 cm (4.92”x 4.92”x 4.68”)(3) KT2C
• Weight: 0.6 Kg (1.32 lb)
