Overview
Thirty AMP Power Distribution System with Remote Control Capability
The CQ-3000 is necessary for high current, low frequency amplifier control. The same size as the CQ-2000, this product integrates seemlessly with the other CQ products. It fits anywhere in a chain of sequencers, but is usually located at the end of the system - the last on and the first off.The CQ-3000 features a single 30 amp twist lock connector (NEMA L5-30R). Power control uses a high current relay with large inrush current handling capability. AC mains are attached to the CQ3000 with a hardwire connection to a terminal block inside the chassis. Other features include a 30 amp thermal circuit breaker, a master sequence activation and override switch and operation indicator LED's.
Specifications
- Chassis: 16 gauge steel – mounts through holes in back box
- Dimensions: 9.0”H x 6.0”W x 4.0”D
- Weight: 6 lbs
- Circuit Breaker: 30A thermal on side of the chassis
- Relay Current Rating: 50A
- Number of Sequence Events: One
- Power Input: Hard wire through strain relief on back box
- Power Output: One NEMA L5-30R
- Input Voltage: US standard (120 VAC @60Hz)
- Signal Connections: RJ-45 eight wire cable
- Monitor Features: Monitor lights correlate to processor and relay operation
