Pyro 5 Wireless Transceiving Monitor

Overview

Pyro 5 is a 5.5-inch wireless monitor designed for do-it-all performance. With dual-band transmission, 4-way monitoring via Broadcast Mode, direct camera control, smart channel selection, and a 1500-nit daylight-viewable screen, it combines multiple functions into one compact tool. Proxy recording and RTMP live streaming make Pyro 5 more than just a monitor—it's your multi-tasking hub on set, built to simplify and speed up every step of production.

Pyro 5 is equipped with Auto Frequency Hopping technology, which constantly scans and monitors the strength of the signal and interference across various frequency ranges to find the best wireless channel to use, resulting in a more reliable connection.

Broadcast Mode

In Broadcast Mode, one transmitter connects to up to four receivers with camera views switching and auto frequency hopping. Ideal for multi-cam setups, it delivers stable performance at up to 200m line-of-sight or 100m back-to-back.

Dual-Band Stronger Signal. Smoother Feeds.

Built with a dual-band 2.4G/5G transmission system, Pyro 5 automatically adapts to changing environments—delivering robust, interference-resistant video even in signal-heavy locations.

Multi-Cam Switching.

Pyro 5 supports switching between camera groups, keeping up with fast-paced live productions.

Lock Pairing.

When multiple Pyro systems are in use, Lock Pairing ensures each receiver stays securely connected to its original transmitter—no signal mix-ups.

Pyro 5 is equipped with Auto Frequency Hopping technology, which constantly scans and monitors the strength of the signal and interference across various frequency ranges to find the best wireless channel to use, resulting in a more reliable connection.

Smart Channel Selection

At startup, the system automatically scans and locks onto the optimal frequency channel. Channels can also be manually scanned and switched via the receiver, with visual signal strength indicators for each frequency.

Built to Feel Good. Made to Last.

A dual-injection shell keeps the device light in hand and strong enough to handle the roughest shoots. The Easy-install antennas make setup, transport, and storage faster and easier than ever. Every detail is designed for the field—from the rugged build to the streamlined setup

Go Live, Anywhere. RTMP Streaming

Stream directly to Zoom, YouTube Live, TikTok, and more with the HollyView App and RTMP support. Just connect a 4G LTE Wi-Fi modem, enter your stream key, and you're live—no extra setup needed.

Specifications

• Input Port
• Transmitter Mode: HDMI 1.4b + 3G SDI
• Receiver Mode: /
• Output Port
• Transmitter Mode: Loop-Out HDMI 1.4b
• Receiver Mode: HDMI 1.4b
• Audio-Video Parameters
• Transmitter Mode: Color Depth Capability
• Transmitter Mode: Input Audio Format
• Transmitter Mode: Output Audio Format
• Receiver Mode: HDMI Input: YUV422/YUV444 8BIT
• Receiver Mode: HDMI 1.4b 8-Channel
• Antenna: SMA Male
• Power Input: DC Input (2.0mm core socket)
• Headphone Jack: 3.5mm
• Upgrade Port: USB-C (USB 2.0 OTG) / SD Card Slot
• Screen Size: 5.5″ Touchscreen
• Screen Resolution: 1920*1080 Pixels
• Color Gamut: Rec.709
• Aspect Ratio: 16: 9
• Screen Brightness: 1,500 nits
• Contrast Ratio: 1000:1
• Power Input Voltage: NPF: 6V~16V, DC-in: 10-18V DC
• Video Processing Technology
• Transmitter Mode: Video Bitrate
• Transmitter Mode: Video Encoding Format
• Receiver Mode: Maximum 12 Mbps
• Receiver Mode: H.264
• Power Consumption
• Transmitter Mode <16.5W
• Receiver Mode <14W
• Net Weight: ≈ 410g (14.5oz)
• Dimensions: (L×W×H): 151.6×102.3×40.5mm
• Operating Frequency
• 5.150-5.250GHz
• 2.412~2.484GHz
• 5.250-5.350GHz
• 5.470-5.600GHz
• 5.600-5.725GHz
• 5.725-5.850GHz
• Transmit Power: Transmitter Mode: < 23dBm
• Receiver Sensitivity: Receiver Mode: Unicast: -85dBm; Broadcast: -80dBm
• Transmission Latency: ≈60ms (Tested in a laboratory environment with 1080P60 signal transmission)
• Bandwidth: Unicast: 20 MHz Broadcast: 40 MHz
• Operating Temperature: – 10℃ – 45℃
• Storage Temperature: – 40°C – 45°C
• HDMI Input
• 720p50/59.94/60
• 1080i50/59.94/60
• 1080p23.98/24/25/29.97/30
• 1080p50/59.94/60
• HDMI Loopout/Output
• 720p50/59.94/60
• 1080i50/59.94/60
• 1080p23.98/24/25/29.97/30
• 1080p50/59.94/60
• SDI Input
• 1080p50/59.94/60 (Level A)
• 1080p50/59.94/60 (Level B)
• 1080i50/59.94/60
• 1080p23.98/24/25/29.97/30
• 1080psf23.98/24
• 1080psf25/29.97/30
• 720p50/59.94/60
• SDI Loopout/Output
• 1080p50/59.94/60(Level A)
• 1080i50/59.94/60
• 1080p23.98/24/25/29.97/30
• 1080psf23.98/24
• 1080i50/59.94/60
• 720p50/59.94/60

Pyro 7 Wireless Transceiving Monitor

Overview

Pyro 7 is a 7-inch wireless monitor that integrates the functionalities of TX, RX, and monitor, all in one. It utilizes Auto Dual-Band Hopping (ADH) technology. With 1,300ft (400m) and an incredibly low latency of only 60ms, Pyro 7 supports 2.4GHz/5GHz dual-band transmission and automatic frequency hopping. Its exceptional hardware design enables Pyro 7 to simultaneously connect one transmitter to four receivers, and the convenience of dual-camera monitoring is achieved through customizable shortcut keys. Additionally, the upgraded HollyOS system provides enhanced image analysis capabilities and allows for video file export via an external SD card. Pyro 7 is compatible with Pyro H and Pyro S, which means you can easily pair Pyro 7 with either Pyro H or Pyro S. This provides you with greater flexibility and scalability to meet various monitoring needs.

More Flexible. Meet More Monitoring Needs.

Pyro 7's WifiBroadcast technology enables one transmitter to connect to four receivers with stable signals, offering more flexibility when additional monitoring needs emerge on set.

Broadcast Mode

Activated

When Broadcast mode is activated, the transmitter can transmit signals to a max of four receivers.

Deactivated

When Broadcast mode is deactivated, the transmitter can transmit signals to at most two receivers and two mobile devices.

*Connection to the monitoring app may affect the transmission range.

Dual Boosts.Less Latency and More Stability.

Compared to traditional video transmission systems whose range extends at the cost of image quality and latency, Pyro S excels with increased transmission distance while preserving video quality and minimizing latency.

ADH Auto Dual-Band Hopping

With our developed Auto Dual-Band Hopping (ADH) technology, Pyro 7 operates on both 2.4 GHz and 5 GHz dual-bands and features intelligent Auto Frequency Hopping, so it can automatically choose the clearest channel. This feature guarantees reliable and uninterrupted wireless video transmission.

Dual Band 2.4 GHz & 5 GHz.

Pyro 7 offers a dual-band transmission solution that addresses common issues such as signal interference, low transmission efficiency, and frequency congestion. And the omnidirectional high-gain antennas will also ensure stable signals in all directions. This provides better signal transmission performance and efficiency. With Pyro 7, you won't have to worry about video drop issues any more.

Intelligent Auto Frequency Hopping

Pyro 7 is equipped with Auto Frequency Hopping technology, which constantly scans and monitors the strength of the signal and interference across various frequency ranges to find the best wireless channel to use, resulting in a more reliable connection.

Seamless Connectivity
HDMI and SDI Input/Output/Loopout

Pyro 7 is the perfect solution for professional shooting and smaller commercial projects. The transmitter features one HDMI input, one SDI input, and one HDMI loopout, while the receiver provides one SDI output, one HDMI output, and one SDI loopout.

Interference-free
SmartChannel Scan.

Pyro 7 is the perfect solution for professional shooting and smaller commercial projects. The transmitter features one HDMI input, one SDI input, and one HDMI loopout, while the receiver provides one SDI output, one HDMI output, and one SDI loopout.

Real-Time Messaging Protocol
RTMP Streaming

With the HollyView App and the power of RTMP (Real-Time Messaging Protocol), just input your wireless key and connect 4G LTE Wi-Fi Modem to easily stream video to popular live broadcasting or conferencing platforms like Zoom, YouTube Live, Twitch, TikTok Live, and others. Pyro 7 will offer you a convenient live streaming experience.

Features

• 1TX & 4RX (1 Monitor in box)
• 1300ft (400m) & 0.06s Latency
• 2.4 GHz & 5 GHz Dual Band
• Auto Frequency Hopping
• TX, RX, and Monitor – All in One
• Dual-View Quick Monitoring Switch
• 7-Inch & 1500 nits
• Precise Image Analysis
• SDI & HDMI Loopout
• RTMP Streaming

Specifications

• Input Port: HDMI 1.4b + 3G SDI
• Output Port: HDMI 1.4b + 3G SDI
• HDMI 1.4b + 3G SDI: RP-SMA Male*2
• Power Input: DC Input (2.0mm core socket)
• Headphone Jack: 3.5mm
• Upgrade Port: USB-C (USB 2.0 OTG) SD Card Slot
• Screen Size: 7" Touchscreen
• Screen Resolution: 1920 × 1200 pixels
• Pixel Density: 323 PPI
• Aspect Ratio: 16:9
• Screen Brightness: 1200 nits
• Contrast Ratio: 1000:1
• Power Input Voltage: 10 - 18V/2.5A DC Input (nominal 12V)
• Power Consumption: < 22W
• Net Weight: 545g (19.2oz) with battery plate included and external antennas excluded
• Dimensions (L × W × H): 180 × 127 × 31.8mm (7.1" × 5" × 1.25") with battery plate and external antennas excluded
• Operating Frequency: 5.1 - 5.8 GHz; 2.412 - 2.484 GHz
• Transmit Power: ≤ 23 dBm
• Receiver Sensitivity: -80 dBm
• Display Latency: < 50ms
• Transmission Latency: ≈ 60ms (test data when 1080p60 signals are transmitted in a laboratory)
• LOS Range: •1,300ft (400m)* (Connection to the monitoring app may affect the range); •650ft (200m)* (in Broadcast mode)
• Bandwidth: 20 MHz; 40 MHz (in Broadcast mode)
• Audio Format: HDMI 1.4b 8-Channel
• Operating Temperature: - 10℃ - 45℃
• Storage Temperature: - 40℃ - 60℃
• HDMI Input
• 720p50/59.94/60
• 1080i50/59.94/60
• 1080p23.98/24/25/29.97/30
• 1080p50/59.94/60
• 3840*2160 23.98/24/25/29.97/30
• HDMI Loopout
• 720p50/59.94/601080i50/59.94/601080p23.98/24/25/29.97/301080p50/59.94/60 3840*2160 23.98/24/25/29.97/30
• SDI Loopout
• 720p50/60 1080i50/60 1080p24/25/30 1080p 50/60 1920*1080 24/25/30
• HDMI/SDI Output
• 720p50/60 1080i50/60 1080p24/25/30 1080p 50/60 1920*1080 24/25/30
