Overview

The Hospitality Industry needs a battery-free wireless keycard switch that harvests energy from the insertion of thecard into the switch housing. The PTM265KCA answersthis need using an integrated mechanical energy harvesterand radio to transmit switch state to embedded receivers.

Any facility with guest rooms can take advantage ofwireless technology to retrofit suites and buildings soenergy loads are only operational when needed, reducingenergy consumption and costs.

Assign a switch to as many relays as needed withno limitations.

Each controller can have up to 20 sensors or switchesassigned to it. Radio range in line-of-sight applications isoften better than 300’. Interior spaces with walls and otherobstacles will safely allow for 80’ range.

A reduction in your energy costs can be achieved with KeyCard wireless switches and Echoflex controllers.

Specifications

Technical Specifications

• Operating Mode: Card Inserted, Card Extracted
• Power Generation: Electrodynamic Energy Harvester

Communications

• Radio Frequency: 902MHz (U) or 868 MHz (Y)
• Antenna: Integrated whip
• Transmission Range: 24 m(80 ft) - commercial office spaces (typical), up to 100 m (330 ft) line of sight

Mechanical Specifications

• Operating Temperature: -25°C to 65°C(-13°F to 145°F )
• Relative Humidity: 5% to 92% RH (non-condensing)
• Weight: 142 g (5 oz)
• Dimensions: 115 x 71mm x 35.8mm (4.5 x 2.8 x 1.4“)
• Life Cycle: 50,000 actuations
• Mounting: Screws or double double sided tape (not supplied)
• Card Format

  • ISO/IEC7810 - ID-1
  • 85.60 x 53.98 mm (3.37 x 2.125”)
  • thickness 0.76 mm (0.03”)
