Electro-Voice RE3-RE520-5L

Electro-Voice RE3-RE520-5L

Electro-Voice RE3-RE520-5L

Electro-Voice RE3-RE520-5L

Handheld set with RE520 head 488-524 MHz

SKU: EV-F.01U.354.219
MSRP: $937.00

Achieve solid performance, dependability, and clear voice reproduction with the Electro-Voice RE3-RE520 (Band 5L: 488 to 524 MHz) UHF wireless handheld microphone system. Comprised of a rack-mountable diversity receiver and one handheld wireless transmitter with an RE520 supercardioid condenser microphone capsule, this wireless set is well suited for singers, speakers, and presenters in clubs, concert venues, houses of worship, and conference rooms. The RE520 delivers full and detailed vocal tone, enhanced off-axis rejection, and high gain before feedback. Thanks to simple operation and the ability to control the transmitter from the receiver, the RE3-RE520 minimizes setup time and maximizes workflow efficiency.

Two included AA batteries provide up to eight hours of operating time for the transmitter, which offers adjustable sensitivity and RF output power to optimize your gain structure and avoid clipping. Backlit LCD screens display crucial information such as transmitter battery status, frequency, KeyLock mode, and mute status. Easily sync, scan, and control this wireless system via its dedicated buttons and straightforward menu navigation.

Features:

  • For Singers, Speakers & Presenters
  • Rack-Mountable Diversity Receiver
  • Wireless Handheld Mic Transmitter
  • RE520 Supercardioid Condenser Mic Head

Specs:

Electro-Voice RE3-RX5L Diversity Wireless Receiver (488 To 524 MHz) Specs
System
Wireless Transmission Digital UHF
Number of RF Channels 1440
Diversity Antenna Diversity
RF Frequency Band 488 to 524 MHz
RF Bandwidth Up to 36 MHz
Modulation Wideband FM
Receiver
Form Factor Tabletop
Mounting Options Rackmount (with Included Hardware)
Rackmount Size 1 RU (1/2 Rack)
Antenna 2 x 1/2 Wave External, Detachable (Rear-Mount)
Antenna Bias Voltage 12 to 15 VDC
Number of Audio Channels 1
Audio I/O 1 x XLR 3-Pin Male Balanced Line Output
1 x 1/4" TS Male Unbalanced Line Output
Frequency Response 51 Hz to 16 kHz (Dependent on Mic)
Approximate RF Sensitivity 81 dBm
RF Output Power Up to 50 mW (Max)
Power Requirements AC/DC Power Adapter
AC/DC Power Adapter 12 to 15 VDC (Included)
Display & Indicators Backlit LCD (Battery Status, Channel, Diversity, Frequency, Group, Mute, Power)
Housing Metal
Dimensions 8.2 x 1.9 x 6.1" / 20.8 x 4.8 x 15.5 cm (without Mounting Hardware)
Electro-Voice RE3-HHT5205L UHF Wireless Transmitter With RE520 Condenser Supercardioid Capsule (488 To 524 MHz) Specs
System
Wireless Transmission Digital UHF
RF Frequency Band 488 to 524 MHz
RF Bandwidth Up to 36 MHz
Encryption Yes
Modulation Wideband FM
Transmitter
Form Factor Handheld
RF Output Power 10 mW (50 mW Peak, Switchable)
Audio I/O None
Muting Mute Switch
Frequency Response 50 Hz to 20 kHz (Dependent on Mic)
Sync Method IR
Power Requirements Battery
Battery Type 2 x AA (Included, Replaceable)
Display & Indicators LCD (Channel, Group, Mute, Power, RF Output Power)
Housing Metal
Dimensions 1.4 x 7.5" / 3.6 x 19.1 cm
Weight 12.2 oz / 345.9 g (without Capsule)
Microphone
Form Factor Handheld Capsule
Sound Field Mono
Capsule Condenser
Polar Pattern Supercardioid
Frequency Range 50 Hz to 20 kHz
SNR Supercardioid: 72 dB
Equivalent Noise Level Supercardioid: 22 dB A-Weighted
Maximum SPL 139 dB SPL Peak
Sensitivity 5.6 mV/Pa at 1 kHz
Dynamic Range 117 dB A-Weighted
Operating Voltage 4 to 8 V
Length 3.3" / 8.38 cm
Diameter 2.0" / 50.80 mm
Weight 4.6 oz / 130.41 g
