Features
- Designed for air-handling spaces
- Ported enclosure for extended bass response
- Waveguide-coupled 0.75-inch titanium-coated tweeter
- Full-bandwidth overload protection
- Integrated transformer for 70 V, 100 V, or 8 Ω use
- Front-panel mode/wattage selector
- Safe, easy installation with included tile bridge and mounting ring
- White semi-gloss perforated grille
- Complete package, requires no additional accessories
Specifications
| Available Color | White (paintable surface) |
| Chassis Size | 4" (101.6mm) |
| Coverage (Nominal -6 dB) | 130 (conical) |
| Diameter (Max) | 7.13" (181mm) |
| Enclosure Material | Steel enclosure and UL94V-0 rated baffle and bezel |
| Grille | Powder-coated steel |
| HF Transducer | 0.75-inch (19 mm) Ti Mylar Laminate Dome |
| Input Formats | 8ω, 70 V, 100 V |
| LF Transducer | 4-inch polypropylene cone |
| Mounting Systems | Integrated 3-point toggle anchors |
| Power Rating | 200W |
| Regulatory Approvals | UL1480; UL2043 |
| Sensitivity 1 W/1 m | 86dB |
| Speaker Type | Ported cabinet, internally damped, two-way (passive crossover included) |
| System Power Handling (Continuous/Program/Peak) | 50Watts (Overload Protected) |
| Transformer | Yes |
| Transformer Taps (Transformer Version Only) | (1.88 - 70 V only), 3.75, 7.5, 15, 30 |
| Weatherized | No |
