Specifications

• Frequency Response: 65hz – 20khz
• Max SPL: 138 dB
• Operating Mode

  • Amplifier Channels: Single-amp LF/HF; Bi-amp LF, HF
  • External Signal Processing: High pass filter; DSP w/2-way filters
• Subsystem

  • LF – 1x 12 in. cone
  • HF – 1x 1.4 in. exit, 3 in. voice coil compression driver
• Nominal Beamwidth

  • Horizontal: 90
  • Vertical: 60
• Power Handling

  • Full Range: 600W @ 8ohms
  • LF: 600W @ 8ohms
  • HF: 150W @ 8ohms
• Connections: Barrier Strip
• Dimensions

  • Height: 30 in (762 mm)
  • Width: 15.54 in (394.7 mm)
  • Depth: 14.75 in (374.7 mm)
• Weight: 60 lbs (27.2 kg)
