Overview
The MKD installation loudspeaker series is engineered to deliver the high output, broadband pattern control and exceptional fidelity that is required by real-world applications from stadiums to intimate music clubs.
MKD builds on EAW's long standing tradition of exceptional installation focused loudspeakers developed in partnership with consultants and sound system integrators worldwide. The compact durable Baltic birch enclosure provides for easy installation with an array of M10 mounting points and optional wall-mount or ceiling-mount brackets. MKD also offers weather protection options, custom colors, and a gently curved front allow for concealed installations in the most visually sensitive environments.
MKD leverages the design tenets and core technologies deployed in our QX series by deploying a pair of spaced low frequency transducers centered around a large format rotatable horn. The acoustically advanced transducers are able to be driven an octave lower than standard drivers through the use of our beamwidth matched crossover technology.
Features include:
- High output passive or bi-amplified two-way performance
- QX inspired 4in voice coil compression driver with extended
- Precision EAW signature broadband pattern control
- Flexible mounting, weather protection, color and transformer options
Specifications
Frequency Response
47Hz – 20kHz
Max SPL
147 dB
Operating Mode
Passive, Bi-Amp
Subsystem
2 x 12in Cone, 3in Voice Coil, Vented
1 x 2in Exit, 3.5in Voice Coil, Compression Midrange, Horn Loaded
1 x 2in Exit, 1.75in Voice Coil, Compression driver, Horn Loaded
Nominal Beamwidth
60° Horizontal
45° Vertical
Power Handling
LF/MF/HF 1200W @ 8ohms
LF 1200W @ 8ohms
HF/MF 140W @ 8ohms
Connections
Terminal Block
Dimensions
Height: 32 in
Width: 22.7 in
Depth: 20.6 in
Weight
104 lbs. (47.2kg)
