Overview

The KF810P incorporates specific design features tailored for the installation market: clean aesthetics offered in black or white, invisible wiring, and concealed 3-point rigging. A weather rated option allows for long term permanent installation in demanding environments backed by EAW’s full warranty.

Engineered for a wide variety of applications, the compact KF810 module is comprised of dual 3″ voice coil high frequency compression drivers, four 5″ mid-frequency transducers and two 3″ voice coil high power 10″ LF drivers. The output of these sources unites through an integrated horn that occupies nearly the entire forward face of the speaker enclosure, delivering up to 145dB with accurate pattern control to 250Hz to master the most challenging acoustic spaces.

• Best in Class Acoustic Performance
• Optional 80° or 110° Dispersion
• Ultra-Clean Look
• Concealed Wiring and Rigging

Specifications

Frequency Response

50 Hz to 20 kHz

Max SPL

145dB

Operating Mode

Bi-amp LF, MF / HF
DSP w/EAW Focusing

Subsystem

LF 2X 10in, 3.0in VC
MF 4X 5in, 1.7in VC
HF 2X 1.4in exit, 3in VC

Nominal Beamwidth

Horizontal – 110° or 80°
Vertical – 10°

Power Handling

LF 1000W @ 8ohms
MF/HF 500W @ 8ohms

Connections

Barrier Strip

Dimensions

Height: 12.6 in (320 mm)
Width: 32.9 in (835 mm)
Depth: 17.4 in (443 mm)

Weight

88lbs (40 kg)
