Overview

The ELE738 is a bundle consisting of four ELE700 ElectraPix Par 7 fixtures and their related accessories.

ADJ's ElectraPix Par 7 LED Par is a compact wireless DMX lighting powerhouse. With seven 20-watt Hex Color LEDs, individual pixel control, and versatile dimming options, it offers dynamic lighting possibilities for production designers. The unit operates on battery or wall power and provides 5 hours of standard battery run time or 10 hours in saver mode. Featuring an IP65 ingress rating, OLED display, L Track system, and flexible control options, including DMX512, Aria X2 Wireless DMX, Bluetooth, and UCIR24 remote, it adapts seamlessly to almost any application. With certifications for reliability and included accessories like an outdoor locking power cable and UCIR24 remote, this fixture is another versatile ADJ lighting solution you'll want in your production toolkit. Illuminate with purpose and performance using ElectraPix Par 7.

ADJ ElectraPix Par 7 Pak Includes:

• Outdoor Locking Power Cable
• (6) UCIR24 Remote
• (6) Gel Frame
• (6) 20° Diffusion Filter

ADJ ElectraPix Par 7 Pak Features:

• 7 Pixel, Hex Color LED (RGBAL+UV) LED Par
• Battery or wall-powered
• 5 Hour Standard Battery Operation and 10 Hour Saver Battery Operation (Menu Option)
• Individual Pixel Control
• Built-In Foreground LED Programs
• Built-In Background LED Programs
• Variable White Color Temperature Control (2,700K ~ 9,900K)
• English & Spanish User Menu
• Built-In Alarm
• Color Calibrated LED's
• User Selectable LED Refresh Rates (900Hz ~ 25K)
• 6 User Selectable Dim Modes
• 4 User-Selectable Dim Curves
• Electronic Strobe (0.3Hz ~ 11Hz)
• Electronic Dimming

ADJ ElectraPix Par 7 Pak Specifications:

• Source
  • (7) 20W Hex Color RGBAL+UV Foreground LED's
  • (29) 0.2W RGB Background LED's
  • 50,000 Hour Average Life*
  • *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
• Optical
  • 2,300K ~ 9,900K White Color Temperature Range
  • 17° Beam Angle
  • 45mm Lens Diameter x8
• Physical
  • IP65 Housing
  • OLED Digital display
  • L Track system for locking accessories/rigging
  • Gel Frame Holder
  • Adjustable, hanging / kickstand bracket
• Control
  • DMX512
  • Aria X2 Wireless DMX
  • Bluetooth
  • RDM and RDM Net Compatible
  • IR (Includes UCIR24 wireless remote)
  • (4) DMX Channel Modes (5, 6, 9, 13, 21, 24, 42, 45 & 54 Channel modes)
  • On-board Manual Control Mode
  • Primary / Secondary Mode
• Connections
  • 5pin XLR Outdoor DMX In/Out Sockets (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
  • Outdoor Locking Power Sockets
  • Battery Charging Socket
• Dimensions & Weight
  • Length: 11.11” (282.1mm) Width: 9.77” (590.3mm) Height: 7.46” (189.5mm)
  • Weight: 15.4 lbs. (7 kg)
• Power
  • AC100-240V/50Hz-60Hz Input
  • 60W Power Consumption
  • Link 15 pieces @120VAC or 28 pieces @ 230VAC
  • Battery
  • Rechargeable Lithium-ion
  • Battery Capacity: 7,000mAh
  • Battery Voltage: 22.2V
  • Charge Time: 6 Hours (To Full)
  • 5 Hour Standard Operation at Full Output and 10 Hour Saver Mode Operation at Full Output Selectable in the menu
  • Battery Cycles: 500
• Thermal
  • Ambient Operational Temperature: -4°F to 113°F (-20°C to 45°C)
  • Storage Temperature: -22°F to 113°F (-30°C to 45°C)
• Certifications & IP Rating
  • CE
  • cETLus (Pending)
  • FCC
  • IP65
• Included Accessories
  • (1) Outdoor Locking Power Cable
  • (1) UCIR24 Remote
  • (1) Gel Frame
  • (1) 20° Diffusion Filter
• Optional Accessories
  • LTrack A2 (LTrack Adapter Only)
  • LTrack CA2 (LTrack Adapter with Narrow Clamp)
  • ELP12IPBDA (Barn Door and Gel Frame Assembly, Sku: ELP404)
